Overview:

The VM-Series supports the exact same next-generation firewall and advanced threat prevention features available in our physical form factor appliances allowing you to safely enable applications flowing into and across your private public and hybrid cloud computing environments.

Automation features such as VM monitoring dynamic address groups and a REST-based API allow you to proactively monitor VM changes dynamically feeding that context into security policies thereby eliminating the policy lag that may occur when your VMs change.

The VM-Series Virtualized Next-Generation Firewall

Protect applications and data deployed across a wide range of public cloud virtualization and NFV environments.

Identify and control applications grant access based on users and prevent known and unknown threats.
Segment mission-critical applications and data using Zero Trust principles to improve security posture and achieve compliance
Centrally manage policies across both physical and virtualized firewalls to ensure consistent security posture.
Streamline workflow automation to ensure that security keeps pace with the rate of change in your cloud.

The VM-Series: Protect Any Cloud

Organizations are quickly adopting multi-cloud architectures as a means of distributing risk and taking advantage of the core competencies of different cloud vendors. To ensure your applications and data are protected across public cloud virtualized data centers and NFV deployments the VM-Series has been designed to deliver up to 16 Gbps of App-ID-enabled firewall performance across five models:

VM-50/VM-50 Lite &mdash engineered to consume minimal resources and support CPU oversubscription yet deliver up to 200 Mbps of App-ID-enabled firewall performance for customer scenarios from virtual branch office/customer-premises equipment to high-density multi-tenant environments
VM-100 and VM-300 &mdash optimized to deliver 2 Gbps and 4 Gbps of App-ID-enabled performance respectively for hybrid cloud segmentation and internet gateway use cases.
VM-500 and VM-700 &mdash able to deliver an industry-leading 8 Gbps to 16 Gbps of App-ID-enabled firewall performance respectively and can be deployed as NFV security components in fully virtualized data center and service provider environments.

VM-Series Models

To make sure that you purchase the correct model for your network requirements use the following table to understand the maximum capacity for each model and the capacity differences by model:

Model	Sessions	Security Rules	Dynamic IP Addresses	Security Zones	IPSec VPN Tunnels	SSL VPN Tunnels
VM-50	50000	250	1000	15	250	250
VM-100 VM-200	250000	1500	2500	40	1000	500
VM-300 VM-1000-HV	800000	10000	100000	40	2000	2000
VM-500	2000000	10000	100000	200	4000	6000
VM-700	10000000	20000	100000	200	8000	12000

VM-Series System Requirements

VM-Series Model	Supported Hypervisors	Supported vCPUs	Minimum Memory	Minimum Hard Drive
VM-50	ESXi KVM HyperV	2	4.5GB	32GB (60GB at boot)
VM-100 VM-200	ESXi KVM HyperV AWS Azure NSX SDX	2	6.5GB	60GB
VM-300 VM-1000-HV	ESXi KVM HyperV AWS Azure NSX SDX	2 4	9GB	60GB
VM-500	ESXi KVM HyperV AWS Azure NSX	2 4 8	16GB	60GB
VM-700	ESXi KVM HyperV AWS Azure	2 4 8 16	56GB	60GB

Key VM-Series Features and Capabilities:

The VM-Series protects your applications and data with next-generation security features that deliver superior visibility precise control and threat prevention at the application level. Automation features and centralized management allow you to embed security into your application development process ensuring security can keep pace with the speed of the cloud.

Application visibility for informed security decisions:
The VM-Series provides application visibility across all ports meaning you have far more relevant information about your cloud environment to help you make rapid informed policy decisions.
