AMD EPYC 9004/9005 Series Processors; System on Chip; Support up to DDR5 24 DIMM slots (2DPC), speed up to 5200MT/s (Please check System Memory Section for detail); 24 NVMe (PCIe 5.0 x8); 2 PCIe 5.0 x16 Molex Impel plus connector; M.2 Interface: 1 PCIe 3.0 x4, 1 PCIe 3.0 x2; M.2 (22110); 4 USB 3.0 ports (2 rear via riser + 2 via header)
| Form Factor | Proprietary |
|---|---|
| Dimension | 13" x 11" (33.02cm x 27.94cm) |
| CPU | Single processor(s) AMD EPYC 9004/9005 Series Processors (* AMD EPYC 9005 Series drop-in support requires board revision 2.x) |
| Core Count | Up to 160C/320T |
| Memory Voltage | 1.1V |
| Error Detection | Corrects single-bit errors Detects double-bit errors (using ECC memory) |
| Chipset | System on Chip |
| IPMI | ASPEED AST2600 BMC |
| LAN | 1 RJ45 1 GbE Dedicated IPMI LAN port(s) (ASPEED AST2600 BMC) |
| USB | 2 USB 3.0 Type-A port(s) (Rear) |
| Video | 1 Aspeed AST2600 BMC port(s) |
| TPM | 1 TPM 2.0 Header |
Supermicro H13SSH-E is supplied to order. Tell us the configuration you need and our team will confirm pricing and lead time.
