Name: Supermicro MicroCloud A+ Server AS -3015MR-H5TNR - 3U 5-Node MicroCloud with double-width GPU support - AS-3015MR-H5TNR
Brand: Supermicro
SKU: UK-SUP-AS-3015MR-H5TNR
Availability: OutOfStock

Supermicro MicroCloud A+ Server AS -3015MR-H5TNR - 3U 5-Node MicroCloud with double-width GPU support - AS-3015MR-H5TNR

Product code: UK-SUP-AS-3015MR-H5TNR

Condition: New

Availability: Vendor Direct Ship | ETA - Request A Quote | Email: sales@hssl.uk | Call Us: +44 330 043 2524

Request A Quote

Description
Warranty Information
Shipping Policy
Protection Plans

Description

Supermicro MicroCloud A+ Server AS -3015MR-H5TNR - 3U 5-Node MicroCloud with double-width GPU support - AS-3015MR-H5TNR

Key Applications

Cloud Computing
Web/Collocation Services
Web Cache, CDN, Video Streaming
Social Networking, Downloads
Corporate - WINS, DNS, Print, Login

Key Features

Single Socket AM5 (LGA-1718) AMD EPYC 4005/4004 Series Processor up to 170W with air cooling
Support for up to 1 double-width PCIe GPU accelerator card
Up to 4 DIMMs supporting up to 192GB DDR5-5200MT/s (1DPC)/ 3600MT/s (2DPC)
Up to 1 PCIe 5.0 x16 LP + 1 PCIe 5.0 x4 MicroLP slots
Up to 2 internal fixed 2.5" NVMe + 2 internal fixed 2.5" SATA drive bays
4 Redundant 2000W Titanium Level power supplies
3U Rackmount chassis with 30.51" (775mm) depth

Specifications

Product SKUs
A+ Server AS -3015MR-H5TNR

Motherboard
Super H13SRE-F

Processor (per Node)
CPU	Single Socket AM5 (LGA-1718) AMD EPYC™ 4005/4004 Series Processor
Core Count	Up to 16C/32T; Up to 128MB Cache
Note	Supports 65W - 170W TDP CPUs (Air Cooled)* *Air Cooled CPUs with TDP over 120W only supported under specific conditions. Contact a Supermicro representative for details.

GPU (per Node)
Max GPU Count	Up to 1 double-width GPU
Supported GPU	NVIDIA PCIe: L40, L40S, L4, A16, A2, A10 AMD PCIe: Instinct™ MI210

System Memory (per Node)
Memory	Slot Count: 4 DIMM slots Max Memory (1DPC): Up to 192GB 5600MT/s ECC/non-ECC DDR5 UDIMM Max Memory (2DPC): Up to 192GB 3600MT/s ECC/non-ECC DDR5 UDIMM
Memory Voltage	1.1V

On-Board Devices (per Node)
NVMe	NVMe; (Native)
Chipset	System on Chip
Network Connectivity	No NIC option supported

Input / Output (per Node)
USB	2 USB 2.0 ports
Video	1 port
TPM	1 TPM Onboard/port 80

System BIOS
BIOS Type	AMI 32MB SPI Flash EEPROM

Management
Software	SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New!
Power configurations	Power-on mode for AC power recovery ACPI 6.0 Power Management

Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown

PC Health Monitoring
Temperature	Monitoring for CPU and chassis environment
CPU	Monitors for CPU Cores, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory, Chipset Voltages. 3-Phase-switching voltage regulator with auto-sense from 0.5V-2.3V
FAN	Fan speed control, Dual Cooling Zone

Chassis
Form Factor	3U Rackmount
Model	CSE-MC301G-000NFP

Dimensions and Weight
Height	5.16" (131 mm)
Width	17.68" (449 mm)
Depth	30.51" (775 mm)
Package	N/A
Weight	Gross Weight: 147 lbs (66.68 kg) Net Weight: 107.5 lbs (48.76 kg)
Palletized Packing (W x H x L)	27.17" (690 mm) x 16.93" (430 mm) x 44.88" (1140 mm)
Available Color	No Paint

Expansion Slots (per Node)
PCI-Express (PCIe) Configuration	Default 1 PCIe 5.0 x16 FHFL double-width slot 1 PCIe 5.0 x4 MicroLP slot Option A 2 PCIe 5.0 x8 LP slots

Drive Bays / Storage (per Node)
Drive Bays Configuration	Default: Total 4 bays 2 internal fixed 2.5" PCIe 5.0 NVMe drive bays 2 internal fixed 2.5" SATA drive bays
M.2	1 M.2 NVMe slot (M-key 2280/22110)

System Cooling
Fans	5 Heavy Duty 8cm Fan(s)
Air Shroud	10 Air Shrouds

Power Supply

4x 2000W Redundant (3 + 1) Titanium Level (96%) power supplies

Dimension (WxHxL)	73.5 x 40 x 203 mm
Input	1000W: 100-127Vac 1000W: 100-127Vac / 50-60Hz 1800W: 200-220Vac 1800W: 200-220Vac / 50-60Hz 1980W: 220-230Vac 1980W: 220-230Vac / 50-60Hz 2000W: 220-240Vac 2000W: 220-240Vac / 50-60Hz (for UL only) 2000W: 230-240Vdc 2000W: 230-240Vac 2000W: 230-240Vac / 50-60Hz 2000W: 230-240Vdc / 50-60Hz (for China only)
+12V	Max: 83A / Min: 0A (100Vac-127Vac) Max: 150A / Min: 0A (200Vac-220Vac) Max: 165A / Min: 0A (220Vac-230Vac) Max: 166A / Min: 0A (230Vac-240Vac)
12V SB	Max: 3.5A / Min: 0A Max: 3.5A
Output Type	Backplanes (gold finger)

Operating Environment
ROHS	RoHS Compliant
Environmental Spec.	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) Operating Relative Humidity: 8% to 80% (non-condensing) Non-operating Relative Humidity: 8% to 90% (non-condensing)
