The device contains a row of 7500 elements 3 lines photodiodes which provide 24 lines/mm across a A3 size paper. The device is operated by 3.3 V pulse and 3.3 V & 10.0 V power supply
The Toshiba TCD2728DG is a high-performance linear image sensor CCD (Charge Coupled Device) designed for demanding applications requiring exceptional image quality, sensitivity, and reliability. This sensor offers a superior solution for applications such as high-speed document scanning, industrial inspection, spectroscopy, and medical imaging. By employing advanced CCD technology, the TCD2728DG delivers unparalleled precision and clarity, ensuring accurate data capture and analysis.
Benefit from the enhanced sensitivity and low noise characteristics of the TCD2728DG, which allows for capturing detailed images even in low-light conditions. Its robust design and stable performance ensure consistent operation and longevity, minimizing downtime and maximizing productivity. Integrate the TCD2728DG into your systems to achieve outstanding image resolution and uniformity, leading to improved accuracy and efficiency in your data acquisition processes.
Electrical Characteristics
| Characteristics | Symbol | Condition | Value | Unit |
|---|---|---|---|---|
| Power supply voltage (Typ.) | - | - | 3.3/10 | V |
| Sensitivity B/W (Typ.) | - | - | – | V/lx･s |
| Sensitivity R (Typ.) | - | - | 6.7 | V/lx･s |
| Sensitivity G (Typ.) | - | - | 8.5 | V/lx･s |
| Sensitivity B (Typ.) | - | - | 3.1 | V/lx･s |
| Data rate B/W (Max) | - | - | – | MHz |
| Data rate Colour (Max) | - | - | 100 | MHz |
