TP-Link Omada PoE++ Injector. Ethernet interface type: 10 Gigabit Ethernet, Ethernet LAN data rates: 10,100,2500,10000 Mbit/s, Cabling technology: 1000/10000. Product colour: Black, LED indicators: PoE, Power. AC adapter input voltage: 100 - 240 V, AC adapter frequency: 50 - 60 Hz, Input current: 1.6 A. Compliance certificates: CE, Federal Communications Commission (FCC), RoHS. Width: 155 mm, Depth: 70 mm, Height: 42 mm
90W 10G PoE++ Injector
Unlocks peak performance for your 10G/Multi-Gig bandwidth and devices
10G Ports Ensure Faster Connection
Auto-negotiation for 6-speed (10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps /10 Mbps)
Auto Detect the Required Power, Up to 90 W
Standard 802.3af/at/bt for Various Powered Devices
Specifications
| General | |
|---|---|
| Brand | TP-Link |
| Manufacturer part number | POE380S |
| HSSL part number | UK-TPL-POE380S |
| UPC / GTIN | 4895252506341 |
| Product type | PoE Adapters |
| Network | |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,2500,10000 Mbit/s |
| Cabling technology | 1000/10000 |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u |
| Features | |
| Product colour | Black |
| LED indicators | PoE, Power |
| Ports & interfaces | |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Power | |
| AC adapter input voltage | 100 - 240 V |
| AC adapter frequency | 50 - 60 Hz |
| Input current | 1.6 A |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Sustainability | |
| Sustainability compliance | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width | 155 mm |
| Depth | 70 mm |
| Height | 42 mm |
| Packaging content | |
| Number of products included | 1 pc(s) |
| Quick installation guide | Yes |
Specifications are supplied by the manufacturer via Open Icecat and may change without notice. HSSL part number UK-TPL-POE380S.
