Tyan P2111-2M M.2 carrier card
Specifications
Host Bus Type: Host InterfacePCI-E Gen3 x16
Device InterfacePCI-E Gen3 x4 via (2) M.2 (M key) connectors
(1) high-density PCI-E Gen3 x8 for accommodating optional M2110-2M M.2 expansion board
Device Connectivity(2) M.2 (22110/2280/2260/2242)
Physical Dimension: Form FactorHalf height, half length Board Dimension2.53" x 6.59" (64.41 x 167.64mm)
Recommended Tyan products
MBS5630 / S7100 / S7103 / S8030
BBFT77D-B7109 / TN76-B7102 / GT62F-B5630 / GT86C-B5630 / FA100-B7118 / FT48B-B7100/ FT48T-B7105 / GA88-B5631 / TN83-B8251
Operating System
OS supported listSuSE Linux/ SLES / Windows Server 2008, 2008 R2 / Red Hat Enterprise Linux Server / Windows Server 2016 x64 / Windows 10 x64 (1703) / Windows 10 x64 (1709) / RHEL 6.9 x64 / RHEL 7.3 x64 / RHEL 7.4 x64 / SLES 11 SP4 x64 / SLES 12 SP2 x64 / SLES 12 SP3 x64 / CentOS 6.9 x64 / CentOS 7.3 x64 / CentOS 7.4 x64 / Ubuntu 16.04.03 x64 / RHEL 6.4 x64 / RHEL 6.5 x64 / Windows Server 2012 R2 Standard x64 / Windows Server 2016 Standard x64 EN / Windows 10 Pro x64 EN / Windows 8.1 Enterprise x64 EN / Ubuntu 16.04 x64 / Windows Server 2016 Enterprise x64 / Free BSD 11.1 x64 / Free BSD 12.0 x64 / Ubuntu 17.04 x64 / RHEL 7.5 x64 / Ubuntu 18.04 x64 / CentOS 7.5 (1804) x64 / Windows Server 2012 R2 Datacenter x64 / Ubuntu 16.04 x86 / Windows Server 2016 R2 x64 / SLES 12 SP2 x86 / Ubuntu 17.04 x86 / Windows Server 2019 Standard x64 EN / SUSE 11 SP4 X64 / SUSE 12 SP4 X64
Operating Environment: Operating Temp.10° C ~ 35° C (50° F~ 95° F) Non-operating Temp.- 40° C ~ 70° C (-40° F ~ 158° F) In/Non-operating Humidity90%, non-condensing at 35° C
Regulation: FCC (DoC) Class A CE (DoC)Class A
RoHS: RoHS 6/6 Compliant Yes
Package Contains: Card(1) P2111-2M Card Others(1) Low profile bracket
