Lens

• Lens Type: 3.1 to 6 mm
• Aperture: 3.1 to 6 mm：F1.9
• Focal Length & FoV:

3.1 to 6 mm, horizontal FoV: 105.5° to 51.4°, vertical FoV: 55.9° to 28.9°, diagonal FoV: 126.9° to 59.2°

• Focus: Auto, Vari-focal lens, motor-driven lens

Supplement Light:

• Supplement Light Type: IR Light, Warm White Light
• Supplement Light Range:

Video:

3.1 mm to 6 mm: 10 m

Vehicle License Plate:

• mm to 6 mm: 5 m

• IR Wavelength: Warm White Light 3000 K, IR Light 850 nm

Capture Mode

• Trigger Type:  Video Detection, I/O Coil, Radar Mixed Traffic
• Picture Type:  Scene Picture, Scene Picture + Close-up Picture
• Scene Mode:  Entrance & Exit Toll Gate, Underground Parking Entrance & Exit
• Capture Type:  Strobe Light Mode

Capture Parameters

• Image Format:  JPEG
• Capture Resolution: 2688 × 1520
• License Plate Recognition: Forward, Backward, Bidirection
• LED Control: Supports automatic light control/time control of LEDs
• Smart Recognition: ANPR, Motor Vehicle Feature, Vehicle Colour Recognition, Enable Vehicle Manufacturer Recognition
• Capture Picture Overlay:  Location, Capture Time, Plate Number, Capture No., Vehicle Colour Vehicle Type


• WDR: 140 dB
• Main Stream:

50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

• Sub-Stream:

50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)

• Image Settings:

Saturation: 0 to 100

Brightness: 0 to 100

Contrast: 0 to 100

Gain: 0 to 100

3D DNR: Off, Normal, and Expert modes are selectable.

White balance: White Balance 1 and White Balance 2 are selectable.

• Image Parameters Switch: Yes
• WDR Switch: On, Time, Brightness
• Frame Rate: 25 fps (P)/30 fps (N)

Entrance and Exit

• Barrier Gate Control Mode: By Camera/Platform/Mixed
• Keep Boom Pole Open for Following Vehicle: Enable/Disable
• Lock Barrier Gate for Large-Sized Vehicle: Yes
• Relay Output: 2-ch relay output, supporting opening and closing of barrier gates
• Barrier Gate Status: None, Barrier Gate Close In Place, Barrier Gate Open In Place, Remote Control Open In Place
• Allow list and Blocklist:

Up to 100,000 allow list and blocklist totally

Note: Only when the TF card is available, can the function take effect.

Approval

• EMC:

CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EEN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014);

KC (KN 32: 2015, KN 35: 2015)

• Security:

CB (IEC 62368-1: 2014 + A11);

CE-LVD (EN 62368-1: 2014/A11: 2017);

BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005);

• Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• Protection: IK10 (IEC 62262: 2002), IP67 (IEC 60529-2013)

General

• Working Temperature & Humidity

-25°C to 70°C (-13°F to 158°F)

90% or less (non-condensing)

• Power Supply: 12 to 24 VDC/PoE (802.3at, 44 V to 57 V), 300 mA to 230 mA
• Working Consumption: 10 W Max.
• Dimensions: 415 mm × 145 mm × 145 mm (16.34 × 5.71 × 5.71 inch)
• 3.25 kg (7.17 lb.)
• Weight (with Package): 4.3 kg (9.48 lb.)
• Dimensions (with Package): 480 × 435 × 205 mm (18.90× 17.13 × 8.07 inch)
• Storage Conditions:

Temperature: -20 °C to 70 °C (- 4°F to 158 °F)

Humidity: 95% (non-condensing)

• Start-up and Operating Conditions:

Temperature: -30 °C to 70 °C (-22 °F to 158 °F)

Humidity: 95% (non-condensing)

• Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
