Hikvision HM-TD71C8-55/W Thermal Panoramic Scanner
- 360° panoramic view within one camera
- 1280 × 1024 resolution 12 μm, VOx UFPA, NETD ≤ 25 mK (25 °C, F# = 1.0)
- Perimeter detection based on intelligent algorithm: intrusion, region entrance and exit
- Fire detection algorithm
- Alarm linkage: Link other PT cameras to track moving targets when alarms triggered
DatasheetSpecifications
Thermal Module
- Image Sensor: VOx Uncooled Focal Plane Arrays
- Resolution: 26376 x 1280
- Pixel Pitch: 12 μm
- NETD: ≤ 25 mK (@25° C,F# = 1.0)
- Focal Length: 55 mm
- Focus Mode: Semi-auto & Manual
- IFOV: 0.22 mrad
- Aperture: F1.0
- Field of View: 360° × 17.5° (H × V)
- Min. Focusing Distance: 7.5 m
General
- Power Supply: 30 VDC~60 VDC, two-core terminal block
- Power Consumption: Max. 150 W
- Work Temperature/Humidity: From -40°C to 60°C (-40°F to 140°F); Humidity: 90% ± 3% (no condensation)
- Protection Level: IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
- Dimension: 408 mm × 310 mm × 407 mm
- Weight: Approx. 25kg (55.1 lb)
Detection Range Table/Smart Function Range
- VCA Range for Humans: 1000 m
- VCA Range for Vehicles: 3000 m
