Seagate Enterprise Nytro XP6302. SSD capacity: 3.5 TB, SSD form factor: Half-Height/Half-Length (HH/HL), Read speed: 4000 MB/s, Write speed: 2300 MB/s, Component for: Server/workstation
Maximizing Capacity and Performance for Highly Dense Environments
The top challenges for cloud, big data, web hosting and hyperscale data center managers is often a result of the demands of churning through massive amounts of data while reducing complexity, cost and data center space. The solution they select must not only provide the performance they require, but also accomplish it efficiently and within a very small footprint.
As an expansion of the most comprehensive flash-based solutions, Seagate has responded with a low-profile, high-bandwidth application acceleration solution to alleviate much of these stresses, especially for very dense environments. The Seagate® Nytro XP6302 flash accelerator card delivers up to 4TB of raw flash capacity and competitive performance while packing it all in a half-height form factor.
High Performance and Capacity for Even the Densest Environments
The multi-planar design of the Nytro XP6302 flash accelerator card delivers high-capacity flash and performance per slot with innovatively designed flash modules (XFF), making it well-suited for the most compact environments. The Nytro XP6302 card offers a PCIe 3.0 interface to deliver up to 4GB/s of bandwidth for performance-oriented applications like video surveillance and real time data backup, and enables space-constrained server environments and platforms that deploy low-profile boards to run server-based PCIe flash in their data centers.
It Just Works—Reliability and Seamless Deployment
For these large data centers, implementing a reliable and simple solution across a sea of servers is critical and a key driver in the development of the Nytro XP6302 flash accelerator card.
The Nytro XP6302 card not only addresses the challenges of performance and space, but does so seamlessly with minimal administrator intervention or finetuning. Additional sophisticated algorithms and dedicated hardware resources handle complex flash management tasks like garbage collection and wearleveling. Leveraging these advanced features, the Nytro XP6302 cards deliver the performance and endurance needed for critical business applications.
Specifications
| General | |
|---|---|
| Brand | Seagate |
| Manufacturer part number | ST3500KN0012 |
| HSSL part number | UK-SEA-ST3500KN0012 |
| Product type | Internal Solid State Drives |
| Features | |
| Security algorithms | 128-bit AES, 256-bit AES |
| SSD capacity | 3.5 TB |
| SSD form factor | Half-Height/Half-Length (HH/HL) |
| Interface | PCI Express 3.0 |
| Memory type | eMLC |
| Component for | Server/workstation |
| Read speed | 4000 MB/s |
| Write speed | 2300 MB/s |
| Random read (4KB) | 296000 IOPS |
| Random write (4KB) | 148000 IOPS |
| Write latency | 33 µs |
| PCI Express interface data lanes | x8 |
| S.M.A.R.T. support | Yes |
| Certification | WEEE |
| Power | |
| Power consumption (max) | 39 W |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 45 °C |
| Other features | |
| Compliance certificates | RoHS |
Specifications are supplied by the manufacturer via Open Icecat and may change without notice. HSSL part number UK-SEA-ST3500KN0012.
